█Performance parameters

█SDFM50--high-frequency high-precision medium-range laser ranging module

High-precision ranging for medium and long distances: the longest distance is up to 50 meters, with a measurement accuracy of ± 10cm and a repeatability of 1cm, meeting the needs of precise positioning and monitoring.

Strong environmental adaptability: Ambient light resistance up to 100klux, operating temperature range -40°C to 60°C, designed for indoor and outdoor complex working conditions.

Wide range of target reflectivity compatibility: Reliable measurements can be made even for low-reflective targets with 10% reflectivity within the effective range.

Compact and lightweight design: The volume is only 27×30×20mm, and the weight is 15g, which is easy to integrate and install on AGV, hoist and other equipment.

High-performance laser light source: Adopts 905nm laser diode (Class2 laser grade), with a switchable red indicator light for easy debugging.

Flexible communication configuration: supports 3.3V TTL serial port, default baud rate 460800bps (adjustable between 9600 and 921600), and ranging frequency is adjustable from 1Hz to 20kHz.

Stable and reliable power supply: wide voltage input (9-36V DC), power consumption of only 0.8W, good tolerance for voltage fluctuations and electromagnetic interference

◆SDFM50 is a high-precision medium and long-range range-measuring lidar, which supports both indoor and outdoor applications. The SDFM50's technical specifications ensure that the application is required for positioning or collision avoidance monitoring for shuttles, land transporters, overhead cranes and lateral travelers, reliable measurement and detection of extremely dark or shiny materials, and for applications such as thrust, rack occupancy or load height control in logistics applications.

▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁

█ Reasons for customer selection

The SDFM50 uses high-performance 905nm laser technology to achieve non-contact accurate ranging at medium and long distances of up to 50 meters.
It has excellent adaptability to industrial environments, with an operating temperature range of -40°C~60°C, and a strong light resistance of 100klux, ensuring stable operation under complex outdoor working conditions.
The measurement accuracy is up to ±10 cm, and the repeatability is stable at 1 cm, so it can reliably detect even low-reflective targets with a reflectivity of 10%.
It supports adjustable ranging frequency from 1Hz to 20kHz and adjustable baud rate up to 921600bps, with a default configuration of 460800bps, fast response and efficient data output.
With an ultra-compact design (27×30×20mm, 15g), power consumption of only 0.8W, and a wide voltage input (9-36V DC), it is an ideal solution for positioning and collision avoidance of industrial mobile devices such as AGVs and gantry cranes.

▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁

█Advantages and features

Excellent 50-meter medium and long range measurement capability: The longest range is 50 meters, and it can effectively detect even deep dark objects with a reflectivity of 10%, meeting the strict distance requirements of applications such as shelf detection, large equipment positioning and collision avoidance in warehousing and logistics.

Rugged and designed for industrial environments: with 100klux strong light resistance and a wide temperature operating range of -40°C to 60°C, the power supply is resistant to 15% fluctuations, ensuring stable operation in complex indoor and outdoor lighting and temperature differences.

High precision and reliability: The measurement accuracy is ± 10cm, and the repeatability is up to 1cm, ensuring that shuttle vehicles (RGVs), gantry cranes, AGVs, and other equipment achieve accurate parking and safety monitoring.

Compact and easy to integrate: with a volume of only 27×30×20 mm and a weight of 15 g, it can be flexibly installed on space-constrained mobile platforms or mechanical structures.

Flexible and efficient communication configuration: It supports adjustable frequency measurement from 1Hz to 20kHz and adjustable baud rate up to 921600bps, with a default of 460800bps, balancing data real-time and transmission stability.

▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁▁
